MIL-PRF-32504
3.1.3 Entry and exit:
3.1.3.1 Personnel Doors: There shall be a minimum of two (2) Personnel doors, each with dimensions
of 6 -6" high x 3 -0" width. These doors shall have a security entry lock, with internal Safety Bar
operation and equipped with exit signage in accordance with the Unified Facilities Criteria (UFC) 3-600-
01 Section 2-5, "Means of Egress". They shall be outward opening, with a closer or incorporated door
stop. The door and assemblies shall be engineered to withstand 90 mph wind load. Personnel doors
shall be located on opposing walls of the shelter.
3.1.3.2 End Doors, M-LAMS Type A specific: There shall be one each Full Width Door (FWD)
installed on each end of the shelter. The FWD fabric shall be installed between the end door arches.
Any shelter which utilizes a single end door fabric panel which spans between multiple arches or across
the entire end door will not be considered. Each FWD shall be operated by one (1) electric winch. Each
electric winch shall be operated using 110/208V AC power. Each electric winch shall be independently
powered from the shelter s electrical system. Each winch shall be capable of being installed a minimum
of 30 inches above grade. The full width opening doors shall have the capability to be manually opened
and closed should the electrical system fail to deliver power to the winches. Each electric winch shall
have one (1) weather proof motor controlled with a minimum 12 foot cord. Each electric winch shall
incorporate an automatic stop mechanism to limit FWD travel or over-tensioning of FWD lifting cables.
3.1.3.3 End Walls, MLAMS Type V and S specific:
3.1.3.3.1 MLAMS Type V Specific
3.1.3.3.2 The MLAMS end walls shall be flat walls. The shelter shall include One (1) Metal Roll-up
door or one (1) Fabric Sliding door with dimensions of 16 ft +/- 1ft width x 16 ft +/- 1ft height located on
each end wall of the shelter.
3.1.3.4 MLAMS Type S Specific
3.1.3.4.1 The MLAMS-S end walls shall be flat walls. The shelter shall include One (1) Metal Roll-Up
door or one (1) Fabric Sliding door with dimensions of 12 ft +/- 1ft width x 12 ft +/- 1 ft height located on
each end wall of the shelter.
3.1.3.5 Metal Roll-Up Doors (RUD) or Fabric Sliding Doors: Each RUD or Fabric Sliding Door shall
be manually operated from the ground. Each RUD or Fabric Sliding Door shall withstand 90 mph
sustained wind load.
3.1.4 Blackout Protection: The shelter shall prevent detectable light leakage through the shelter outer
fabric cover, vents, door openings and shall provide blackout protection on level and varying terrain at
1,000 feet to the naked eye when using the general illumination lighting system supplied with the shelter.
6
