MIL-PRF-32504
3.1.6.3 Odors: The shelter shall not harbor or emit noxious or toxic odors under all environmental
conditions. The shelter shall not irritate skin or cause other human reactions.
3.1.6.4 Safety: The shelter shall minimize flammability and personnel hazards. The shelter system shall
be physically safe to operate, store, transport and maintain throughout the life cycle of the system.
3.1.6.5 Toxicity: The MLAMS shall not be constructed of materials that shall expose installation team
or operators to any chemicals or chemical compounds deemed hazardous via long-term exposure by
OSHA or NIOSH.
3.1.7 Electrical System: The MLAMS shall be equipped with an electrical system consisting of a main
power panel, junction boxes, lighting, power cables, duplex receptacles, switches, wiring and other items
necessary to supply electrical power and lighting. All components shall conform to the National Electric
Code and meet Underwriter Laboratory approval. The electrical system shall be designed to
accommodate all required circuits and vendor supplied ancillary equipment such as Environmental
Control Units and Powered Heaters. The electrical system shall not require on-site cutting, splicing or
similar methods of assembly. The electrical system shall not require an electrician to install the system.
All connectors shall be weatherproof, rated IP 55 or NEC Type III with either a) twist lock, b) locking, or
c) screw type connectors.
3.1.7.1 Power distribution panel: The electrical system shall accommodate 120/208 Volt, 3-Phase, 200
Amp, 50/60Hz power with built-in main circuit breaker. To ensure compatibility with Military Power
Distribution Systems, the utilization of MIL-DTL-22992 Class L connectors for input power to the power
distribution system is required. The panel shall be capable of accepting and distributing standard
electrical power of five-wire three-phase power as supplied by standard military generators. All circuits
shall be protected by separate, 50/60 Hz circuit breakers. The electrical panel shall be grounded.
3.1.7.2 Electric duplex outlets: The shelter shall provide a minimum of eight (8) each, dual duplex
outlet boxes with 120V, 20 Amp, 50/60 Hz circuit breakers. All terminal outlets shall be ground fault
interrupter (GFI) protected and controlled by circuit breakers within the main electrical panel. The duplex
outlets shall be evenly spaced on each side of the shelter and mounted to the support structure. All
electrical boxes and devices shall be capable of orientation such that water will not have a direct path
to the electrical devices. The outlet shall be re-locatable along the sidewall 30" to 48" above finished
grade.
3.1.7.3 Power connecting cables: All supply and distribution electrical cabling shall be SOOW (Service,
Oil Resistant Insulation and Jacketing, Other Substance, Weather) rated, or equivalent. The cables shall
provide quick disconnect attachment to the main power distribution panel. The electrical cabling system
shall provide sufficient material to allow the inclusion of drip loops to prevent the intrusion of
water into electrical devices. The shelter shall provide provisions to facilitate cable management at a
maximum of 6 foot intervals.
9
