MIL-PRF-32504
4.7 Interface requirements verification: Perform the inspections and measurements in section 4.3
4.7.1 Interoperability and interchangeability demonstration: Compare the test shelter with a similar
MLAMS from existing supply or production run. Test main structural parts from other classes of
MLAMS for interchangeability.
4.7.1.1 Shelter interchangeability demonstration: Erect a baseline shelter and test for the following
configurations (if applicable)
Baseline shelter with test shelter outer fabric skin.
Baseline shelter with test shelter structural framing and shelter fasteners.
Test shelter with baseline shelter outer fabric skin.
Test shelter with baseline structural framing and shelter fasteners.
4.7.1.2 Interoperability and interchangeability criteria: Visually examine each configuration for
compatibility between the baseline shelter components and test shelter components. Verify no binding or
misfit affecting ease of operation, visible openings affecting blackout, or form, fit and function
incompatibilities between the test shelter and the baseline shelter. Inspect each configuration for galling,
abrasion, pinching, mutilation, misalignment, distortion, distention, bent, misshapen or deformed
components or other evidence the reassembled shelters are not totally interchangeable.
4.7.2 ECU duct interface measurement: Measure the diameter (+1, -0) inches of two ECU duct
openings. Verify the presence of weatherproof sleeves.
4.7.3 Electrical Supply: Ensure that the MLAMS main electrical supply panel is compatible with
Military Power Distribution Systems, i.e. - the utilization of MIL-DTL-22992 Class L connectors for
input power to the power distribution panel. The panel shall be capable of accepting and distributing
standard electrical power of five-wire three-phase power as supplied by standard military generators.
4.8 Ownership and support requirements verification: Perform the inspections and measurements in
section 4.4 as applicable.
4.8.1 Shelf life: Demonstrate shelf life by accelerated aging or by analysis.
4.8.2 Durability: Demonstrate durability by accelerated weather or analysis.
4.8.2.1 Marking durability criteria: The nameplate or product markings will be verified by inspection.
4.8.3 Reliability verification: Satisfy the demonstrations defined in section 4.8.3
23
